THK KWVE20-B-E-G3-V2 Linear guideway carriages

Manufacturer: THK
Type: Linear guideway carriages
Model: KWVE20-B-E-G3-V2

width carriage B 63 mm
static moment rating about Z axis M0Z 240 Nm
static moment rating about X axis M0x 332 Nm
dynamic load rating C 13,100

position lubrication connector A3 9.40 mm
lubrication connector N3 M5
maximum tightening torque G2 MA 10 Nm
fixing screws below (DIN ISO 4762-12.9) K3 M5
Material name VMKB_065 KWVE

height system H 30 mm
static moment rating about Y axis M0y 240 Nm
static load rating C0 27,000
overall length carriage L 71.40 mm

maximum permissible screw depth for lubrication connectors t N3 5.50 mm
L2 5.50 mm
fixing screws below (DIN ISO4762-12.9) K6 M5
width rail
