Manufacturer: SICK
Type: Motor feedback systems rotary
Model: SRM50-HWA0-K01
Connection type Male connector, M23, 12-pin, radial
Supply voltage 7 V DC … 12 V DC
Recommended supply voltage 8 V DC
Power consumption 80 mA
Output frequency for sine/cosine signals ≤ 200 kHz
Shaft version Solid shaft
Shaft diameter 10 mm
Flange type / stator coupling Face mount flange, stator coupling
Operating speed ≤ 12,000 min
Angular acceleration ≤ 200,000 rad/s²
Operating torque 1 Ncm
Start up torque + 1.5 Ncm
Number of the absolute ascertainable revolutions 1
Total number of steps 32,768
| Manufacturer | SICK |
|---|---|
| Model | SRM50-HWA0-K01 Motor feedback systems rotary HIPERFACE |
| Condition | New |
| Part No. | 18 |
