SICK IMF12-04NPSVC0S INDUCTIVE PROXIMITY SENSORS 6035456

SICK IMF12-04NPSVC0S INDUCTIVE PROXIMITY SENSORS 6035456

Manufacturer: SICK
Type: INDUCTIVE PROXIMITY SENSORS
Model: IMF12-04NPSVC0S
Art No: 6035456

Housing Cylindrical thread design
Thread size M12 x 1
Diameter Ø 12 mm
Sensing range Sn 4 mm
Safe sensing range Sa 3.24 mm
Installation type Non-flush
Switching frequency 2,000 Hz
Connection type Male connector M12, 4-pin
Switching output PNP
Output function NO
Electrical wiring DC 3-wire
Enclosure rating IP68  IP69K
Special features Resistant to cleaning agents
Special applications Hygienic and washdown zones, Difficult application conditions.

Supply voltage 10 V DC … 30 V DC
Ripple ≤ 10 %
Voltage drop ≤ 2 V
Time delay before availability Approx. 50 ms
Hysteresis 1 % … 20 %
Reproducibility 5 %
Temperature drift (of Sr) ± 10 %
EMC According to EN 60947-5-2
Continuous current Ia ≤ 200 mA
