SICK IM18-20NPS-NC1 INDUCTIVE PROXIMITY SENSORS 6027580

SICK IM18-20NPS-NC1 INDUCTIVE PROXIMITY SENSORS 6027580

Manufacturer: SICK
Type: INDUCTIVE PROXIMITY SENSORS
Model: IM18-20NPS-NC1
Art No: 6027580

Housing Cylindrical thread design
Thread size M18 x 1
Diameter Ø 18 mm
Pressure resistance ≤ 60 bar
Sensing range Sn 20 mm
Safe sensing range Sa 16.2 mm
Installation type Non-flush
Switching frequency 200 Hz
Connection type Male connector M12, 4-pin
Switching output PNP
Output function NO
Electrical wiring DC 3-wire
Enclosure rating IP68, IP69K

Supply voltage 10 V DC … 30 V DC
Ripple ≤ 20 %
Voltage drop ≤ 2 V
Time delay before availability ≤ 40 ms
