SCHUNK PZN+125.1 Universal gripper 303543

Manufacturer: SCHUNK
Type: Universal gripper
Model: PZN+125.1
Art No: 303543

Universal gripper PZN-plus, Size: 125, pneumatic, with gripping force maintenance: IS

Stroke per jaw: 13 mm
Opening force: 4400 N
Max. ambient temperature: 90 °C

Stroke per jaw [mm] 13
Opening force [N] 4400
Opening force (with finger lengths of 0 mm) [N] 5470
Min. spring force [N] 1070
Weight [kg] 3.34
Recommended workpiece weight [kg] 15.5
Fluid consumption double stroke [cm³] 383
Min. operating pressure [bar] 4
Max. operating pressure [bar] 6.5
Nominal operating pressure [bar] 6
Min. air purge pressure [bar] 0.5
Max. air purge pressure [bar] 1
Closing time [s] 0.35
Opening time [s] 0.17
Closing/opening time with spring [s] 0.4
