Leuze electronic FRK 92/4-300L Diffuse sensor with background suppression

Leuze electronic FRK 92/4-300L Diffuse sensor with background suppression

Manufacturer: Leuze electronic
Type: Diffuse sensor with background suppression
Model: FRK 92/4-300L

Series 92

Operating range Guaranteed operating range
Operating range, white 90% 0.005 … 0.3 m
Operating range, gray 18% 0.015 … 0.28 m
Operating range, black 6% 0.02 … 0.26 m
Operating range limit Typical operating range
Operating range limit, white 90% 0.005 … 0.44 m
Operating range limit, gray 18% 0.015 … 0.39 m
Operating range limit, black 6% 0.02 … 0.36 m
Light source LED, Infrared
Wavelength 880 nm
LED group 1
Type of light spot geometry Round

Supply voltage UB 10 … 30 V, DC

Number of digital switching outputs 1 Piece(s)

Type of connection Connector
Thread size M12
Material Metal
No. of pins 4 -pin

egree of protection IP 67
Protection class II
