IFM electronic IE5368 Inductive sensor IEB3002BBPKG/V4A/2M

IFM electronic IE5368 Inductive sensor IEB3002BBPKG/V4A/2M

Manufacturer: IFM electronic
Type: Inductive sensor
Model: IEB3002BBPKG/V4A/2M
Art No: IE5368

Product characteristics
Electrical design PNP
Output function normally open
Sensing range [mm] 2
Housing threaded type
Dimensions [mm] M8 x 1 / L = 27
Electrical data
Operating voltage [V] 10…30 DC
Current consumption [mA] < 15
Protection class III
Reverse polarity protection yes
Outputs
Electrical design PNP
Output function normally open
Max. voltage drop switching output DC [V] 2.5
