Encoder
HEIDENHAIN ROD 486 204801-03 Incremental rotary encoder with integral bearing 376886-22
250.00 $
Availability: 1 in stock
Manufacturer: HEIDENHAIN
Type: Incremental rotary encoder with integral bearing
Model: ROD 486 204801-03
Part No: 376886-22
Output signal TTL
Max. scanning frequency 300.00 kHz
Power supply 5 V (+-10 %)
Flange version
Synchro flange Ø 58 mm, centering collar 50 mm, bolt circle Ø 42 mm, 3 x M4
Shaft Solid shaft, diameter 6 mm, length 9.5 mm
Degree of protection IP66 (EN60529)
Operating temperature -40/+100 °C
Electrical connection free cable end
| Manufacturer | HEIDENHAIN |
|---|---|
| Model | ROD 486 204801-03 Incremental rotary encoder with integral bearing 376886-22 |
| Condition | New |
