BALLUFF
BALLUFF BES 516-105-S4-C Inductive standard sensors BES015N
Dimension Ø 18 x 83 mm
Range 5 mm
Switching output PNP normally open/normally closed (NO/NC)
60.00 $
Availability: 1 in stock
Manufacturer: BALLUFF
Type: Inductive standard sensors
Model: BES 516-105-S4-C
Part No: BES015N
Dimension Ø 18 x 83 mm
Style Housing M18x1
Installation for flush mounting
Range 5 mm
Switching output PNP normally open/normally closed (NO/NC)
Switching frequency 500 Hz
Housing material Brass, nickel-plated
Material sensing surface PA 12
Connection Connector, M12x1-Male, 4-pin
Operating voltage Ub 10…30 VDC
Ambient temperature -25…70 °C
IP rating IP68
| Manufacturer | BALLUFF |
|---|---|
| Model | BES 516-105-S4-C Inductive standard sensors BES015N |
| Condition | New |
