IFM PN7001 Pressure sensor with display PN-250-SBR14-QFRKG/US/ /V

Manufacturer: IFM
Type: Pressure sensor with display
Model: PN7001
Part No: PN-250-SBR14-QFRKG/US/ /V

Number of inputs and outputs Number of digital outputs: 2
Measuring range
0…250 bar
0…3625 psi
0…25 MPa
Process connection
threaded connection G 1/4 internal thread

Special feature Gold-plated contacts
Application for industrial applications Media liquids and gases

Operating voltage [V] 18…36 DC; (to SELV/PELV)
Current consumption [mA] < 35
Min. insulation resistance [MΩ] 100; (500 V DC)
