ELAP RE420C10245R10LD5X13 INCREMENTAL ROTARY ENCODERS

Manufacturer: ELAP

Type: INCREMENTAL ROTARY ENCODERS

Model: RE420C10245R10LD5X13

• Resolution: 1024 pulses per revolution (PPR)
• Supply voltage: 5V DC
• Output signal level: TTL
• Output type: Quadrature A, B, and Z channels with line driver
• Shaft diameter: 10mm
• Shaft length: 24.5mm
• Operating temperature range: -10°C to +70°C
• Protection rating: IP50
• Maximum speed: 6000 RPM
